X Stages

LS-T6039-S6A

0
Thinnest VB X axis stage 60 x 60
Estimate separately
Travel +/-6.5 mm
Table size 60 mm x 60 mm
YESRoHS対応状況

Product documentation

▲PAGE TOP

Description

This is a new product that uses magnetic adsorption.
Achieved an unprecedented thickness of 8 mm.
A low-price product with a different structure from conventional products.
▲PAGE TOP

Specifications

Direction of travel X axis one direction
Table size 60 mm x 60 mm
Clamp method Clamp plate
Mounting position Side
Transfer mechanism Feed screw P=0.5 mm (Hexagon socket head cap screw)
Travel +/-6.5 mm
Lead of actuator 0.5 mm
Guiding method V-groove and steel balls
Load capacity 147 N (15 kgf)
Weight 0.20 kg
Material / Surface treatment Steel/Black chromium oxide
Standard accessories Mounting screw : Cross recessed head machine screw M4, 4 pieces
