TD-604
1
Two axis tilt stage 60 x 60
Estimate separately
Travel
+/- 2°
Table size
60 mm x 60 mm
YES
Product documentation
YES
▲PAGE TOP
Description
Two-axis inexpensive manual tilt stage with manual screws.
The ball between the upper stage and the base becomes the fulcrum of the tilt.
It is widely used for positioning applications such as cameras and sensors.
▲PAGE TOP
Specifications
Direction of travel
Tilt, two axis
Table size
60 mm x 60 mm
Clamp method
-
Transfer mechanism
Manual screw
Travel
+/- 2°
Lead of actuator
Approx. 0°40'
Scale interval
-
Load capacity
39.2 N (4 kgf)
Weight
0.15 kg
Material / Surface treatment
Aluminum alloy/Black Alumite
Standard accessories
Mounting screw : Hexagon socket head cap screw M4, 4 screws
