| Direction of travel |
XYZ, three axis and rotation |
| Table size |
φ50 mm |
| Clamp method |
XYZ axis clamp plate, rotary axis complex clamp |
| Mounting position |
XY axis side |
| Transfer mechanism |
XYZ axis CMH-13RM, Rotary axis CMH-6.5RA (each axis standard micrometer head) |
| Travel |
XY axis +/-6.5 mm, Z axis 0～10 mm, Rotary axis coarse 360°fine +/-5° |
| Lead of actuator |
XYZ axis 0.5 mm, Rotary axis approx. 0.92° |
| Scale interval |
XYZ axis Micrometer head0.01mm,rotaryaxis Vernier reading10′／Micrometer head0.01mm（1 division approx0.018°） |
| Minimum resolution |
XYZ axis 0.003 mm |
| Guiding method |
XYZ axis HG-VCR (V-groove and cross rollers), Rotary axis sliding guide |
| Travel accuracy |
Straightness XY axis 0.002 mm, straightness Z axis 0.003 mm
Circularity 0.05 mm, deflection 0.02 mm |
| Load capacity |
19.6 N (2 kgf) |
| Weight |
0.70 kg |
| Material / Surface treatment |
XY Rotary axis Aluminum alloy/Black Alumite, Z axis Steel, Aluminum alloy/Black chromium oxide, Black Alumite |
| Standard accessories |
Inspection certificate
Mounting screw : Hexagon socket head cap screw M3, 4 screws |
| Supplemental note |
※ For the Z stage is not symmetrical. For more information please check the external view of each product. |
