ARS-936-HA1

0

Rotary stage

Estimate separately

Direction of travel	Rotation
Travel	360°
Table size	φ90 mm

YES

Product documentation

YES

▲PAGE TOP

Description

The combination of a new stepper motor and driver enables low vibration, low drive noise, and high torque.
Motorized rotary (rotation) stage by using ball bearings for moving guide.
The through hole in the the center can be used as a transmission hole.
It is widely used for precision positioning applications such as cameras, sensors, and workpieces.

▲PAGE TOP

Specifications

Direction of travel	Rotation
Travel	360°
Table size	φ90 mm
Motor	Equivalent to PK545NBW (5-wire type pentagonal connection 0.75A/phase)
Resolution	0.004°
Guiding method	Cross roller bearings
Positioning accuracy	0.025°
Repeatability	+/-0.003°
Runout	0.01 mm
Deflection	0.015 mm
Lost motion	0.003°
Parallelism	0.05 mm
Moment rigidity	0.15 sec/N*cm
Load capacity	98 N (10 kgf)
Weight	2.4 kg
Maximum speed	32°/s (at 8,000 pps)
Material / Surface treatment	Steel/Kanigen plating (table), Aluminum/White Alumite (base)
HOME sensor	Normally open contact (make contact, A contact) operation, Photo sensor *non-adjustable
Pre-HOME sensor	Normally open contact (make contact, A contact) operation, Photom sensor *non-adjustable
LIMIT sensor	-
Compatible cable	0.75-A type and 1.2-A type (ACB-BTD2, ACB-BTD3, ACB-BTD-D3, ARC-BTD3 or ARC-BTD-D3, be sold separately)
Standard accessories	Inspection certificate Mounting screw : M4 Hexagon socket head cap screws (3 pcs)
Dedicated parameter setting (Parameter No.4)	11
