This is a 2-axis controller driver equipped with functions necessary for positioning operation.
The motor drive current can be set with a switch. This makes it possible to mix and connect stages with different drive current values ??for each axis.
Equipped with a low vibration driver. Achieves lower vibration drive than conventional drivers.
Jog movement, step movement, teaching operation, one-touch speed switching, etc. are possible with the operation box QT-AK.
The program created by the "QT-EDIT" is stored, and automatic operation of only the controller driver is possible."QT-EDIT" is dedicated application software attached as standard.
The unit display of the operation box (mm, μm, decimal degree, degrees, minutes, and seconds can be simply displayed with symbols, etc.) is possible.
RS-232C is installed as standard as an interface for PC. Independent control of each axis, linear interpolation movement between two axes, and arc interpolation movement between two axes are possible. The S-shaped drive function that enables smooth acceleration and deceleration by trapezoidal drive is installed as standard. Equipped with an electromagnetic brake control function. Electromagnetic brake control is possible by combination of QT-BK (sold separately).

*Before use
For QT-BDL2 and QT-BDL2(K), please set the motor drive current (phase current) before use.
Change the RUN rotary switch on the motor driver unit built into QT-BDL2. The factory setting is 0.75A/phase.
