Classification	Kinematic square mirror holder
Shape conforming element	50×50mm,50.8×50.8mm(2×2″)※2 is the free surface, You can also hold up to about element □ 70mm.

Classification	Kinematic square mirror holder
Shape conforming element	50×50mm,50.8×50.8mm(2×2″)※2 is the free surface, You can also hold up to about element □ 70mm.
Thickness conforming element	2mm to 6mm
The tilt screw Resource	M6P0.25
Adjustable range	±4°
Mounting shaft(mm)	12mm diameter, 60mm length
Weight	0.19kg
Supplemental note	※Three screw version is available.
