Auto Collimator

LAC-TRA-S

1
Tripod stand for LAC(with adjustment mechanism)
Estimate separately

Product documentation

  • カタログPDF
  • 図面PDF
  • 図面DXF
▲PAGE TOP

Features

This is an optional accessory of a laser autocollimator.
LAC-TRA-S is a tripod stand for LAC-S. If you want to fit to the optical axis, there is a convenient fine adjustment mechanism.

※LAC-TRA-S is Nikon Instech Co.,Ltd. will be the distributor.

▲PAGE TOP

Specifications

Product numberLAC-TRA-S
Product nameTripod stand for LAC(with adjustment mechanism)
PriceEstimate separately
X axis travel±30㎜
θx axis travelCoarse360°、Fine±8°
θy axis travel±3°
Maximum height920㎜（944.5㎜）
Minimum height560㎜（584.5㎜）
Weight7.5㎏
