Auto Collimator

C-60L

1
Auto collimator
Estimate separately

Product documentation

Features

C-60L is a simplified auto-collimator, can also be used as a telescope. When used in conjunction with mirror, to measure the straightness of the stage, such as is possible.

Specifications

Product numberC-60L
Product nameAuto collimator
Magnification12×
Effective diameter37㎜
Focal point distance300㎜
Focusing distansInfinity to 1,050㎜
Resolution1′
ReticleCross line
Light sourceWhite LED
PowerAC100V 50/60Hz 0.35A , Cable length 1.8m
IlluminationBright field
WeightBody 3.2kg , controller box 0.8kg
AccessoriesController box (TS-EP2A), AC adapter
