Rotary Stages

RS-313

1
Rotary stage φ30
Estimate separately
Table size φ30 mm
YESRoHS対応状況

Product documentation

▲PAGE TOP

Description

Fine movement rotary (rotation) stage by using a sliding guide for moving guide.
You can rotate the table 360 ??degrees by hand.
It is widely used for positioning applications such as cameras and sensors.
▲PAGE TOP

Specifications

Direction of travel Rotation
Table size φ30 mm
Clamp method Complex clamp
Travel 360° (coarse)
Scale interval Dial reading 5°
Guiding method Sliding
Load capacity 19.6 N (2 kgf)
Weight 0.04 kg
Material / Surface treatment Aluminum alloy/Black Alumite
Standard accessories Inspection certificate
Mounting screw : Hexagon socket head cap screw M2, 4 screws
