Bases & Optical Experiments
Stand
Stand
SV-20P
1
Adjustable stand φ20
Estimate separately
Diameter of the shaft fit
φ20mm
YES
Product documentation
YES
▲PAGE TOP
Description
This is an adjustable stand for 20mm diameter (shaft or pole). It is equipped with three clamp screw holes and can be clamped any clamp screw.
▲PAGE TOP
Specifications
Diameter of the shaft fit
φ20mm
Height
70mm to 75mm
Number of clamp screws
2 (apply from June 1, 2018)
Screws on the bottom
M16P1
Weight
0.15kg
